DPA 503N 三相谐波闪烁测试系统 EMTEST

¥0.00

分类: 设备名称:

Product Description

DPA 503N 三相谐波闪烁测试系统 EMTEST

DPA 503N简介:

DPA 503N是由瑞士EMTEST生产的完全兼容的三相谐波和闪烁分析仪, 谐波和间谐波是由现代电子功率调节模块引起的。这种控制负载和降低功耗的大多数非线性模块是叠加在电源电压上的不需要频率的电压源。由负载电流变化引起的电压波动可能会影响照明系统的亮度或光谱分布。这种光刺激引起的视觉感觉不稳定的印象称为闪烁。DPA 503N 用于三相应用,但也支持单相应用。DPA.CONTROL是用于控制DPA 503N和电源ACS 500进行谐波和闪烁测试的软件。

DPA 503N 测试软件DPA.CONTROL
DPA 503N 测试软件DPA.CONTROL



DPA 503N产品特点:

实时数据采集

用于数据存储的内部硬盘

16 位 A/D 转换器

宽范围电流输入

宽范围电压输入

高精密的分析能力

用于控制和数据传输的 USB 接口

控制外部闪烁阻抗 AIF 503N

DPA 503N技术参数:

HARMONICS ANALYSIS 谐波测试部分参数
As per
  • IEC/EN 61000-3-2 Ed5.1
  • JIS C 61000-3-2 (2019)
  • IEC/EN 61000-3-12:2011
Design as per
  • IEC/EN 61000-4-7 Ed.2.1 (2009)
  • and
  • IEC/EN 61000-4-7 Ed.1 (1991)
Harmonics1st – 50th order
Grouping as perIEC/EN 61000-4-7 (2009) for Interharmonics
SynchronizationPLL; accuracy better than 0.005%
Measuring windowRectangular window (8,10,12,16 periods)
AlgorithmFFT
Smoothing filter1st order 1,5s digital low pass filter (on/off), selectable
Anti-aliasing filter90dB
Measurement durationMore than 30 hours, limited by the hard-disk capability (approx.

1MB/min of measuring data)

DisplayVrms, Irms, Ipeak, Vpeak
HarmonicsV, I, Phase, P, Q, S (2nd – 50th order)
Power informationP, Q, S, Power factor, THD(U), THD(I),

Crest factor(u), Crest factor(i)

FLICKER ANALYSIS 闪烁部分参数
As per
  • IEC/EN 61000-3-3 Ed.3 A2
  • IEC/EN 61000-3-11 Ed2
Design as per
  • IEC/EN 61000-4-15 (2010)
  • 230V, 50/60Hz and
  • 120V, 50/60Hz
Accuracy Pst and PltBetter than 5%
Accuracy dmax, dc, dtbetter than 5%, according IEC 61000-4-15
Flicker dataPst and Plt, Vrms, dmax, dc, dt, P50%S, P10%S, P3%S, P1%S, P0.1%
Maximum valuesPst, dmax, dc, dt
Observation periodMin. 1min, selectable
Standard
  • > EN 301489-1
  • > EN 301489-17
  • > EN 301489-24
  • > EN 301489-7
  • > EN 61000-3-11
  • > EN 61000-3-12
  • > EN 61000-3-2
  • > EN 61000-3-3
  • > EN 61000-4-15
  • > EN 61000-4-7
  • > EN 61000-6-1
  • > EN 61000-6-2
  • > IEC 60601-1-2
  • > IEC 61000-3-11
  • > IEC 61000-3-12 Ed.2:2011
  • > IEC 61000-3-2
  • > IEC 61000-3-3
  • > IEC 61000-4-15 Ed.2:2010
  • > IEC 61000-4-7
  • > IEC 61326
  • > JIS C 61000-3-2
FLICKER IMPEDANCE AIF 503NX (OPTION; SEPARATE UNIT) 选件
Models
  • AIF 503N16 (16 A)
  • AIF 503N32.1 (32 A)
  • AIF 503N63.1 (63 A)
  • AIF 504N75.1 (75 A)
As perIEC/EN 61000-3-3, IEC/EN 61000-3-11 and IEC 60725 for 3-phase applications
Zrefall models
Line L1, L2, L30.24ohm + j0.15ohm
Neutral0.16ohm + j0.10ohm
Ztestexcluding model AIF 503N16
Line L1, L2, L30.15ohm + j0.15ohm
Neutral0.10ohm + j 0.10ohm
AccuracyBetter than 3%
R.M.S. currentDepending on selected model
Each inductor is designed as a non-saturable air coil and is matched manually to the specified value.
OUTPUT FOR VERY LOW CURRENT (AIF 503N OPTION) 选件
VLCM Kit AIF 503N
Measuring outputSeparate output for very low current on phase L1
Current range5mA – 500mA
Accuracy< 1 % of measured value
