Introduction：
NNBL 8226-HV is a LISN-Linear Impedance Stabilized Network (LISN-LISN) tester produced by SCHWARZEBCK and authorized to be sold by our company.NNBL 8226 The continuous operating current is the same at 70A, but the HV version is rated at 800V both DC and AC.
The LISN is designed with 50µH+5Ω impedance and complies with the latest version of AFSL and NTSC EMC test standards, which are listed in the technical data table below.
NNBL 8226-HV
Technical Parameter Sheet:
“Reminder: swipe tables left and right”Model number
NNBL 8226-HV
manufacturer
Schwarzbeck
China Agent Sales
Euttest
Instrument Name
Linear impedance stabilized network
LISN
LISN
Available test standards
MIL-STD-461
GJB151B-2013
GJB151B-2013
Test frequency range
9kHz-100MHz
Maximum continuous operating current
70A
Short-time operating current
100A
Maximum working voltage
DC:800V
AC 50/60Hz: 800V
AC 400Hz: 140V
AC 50/60Hz: 800V
AC 400Hz: 140V
impedance
(50µH+5Ω) || 50Ω ±20%
weight
4.5kg
size
0.22*0.22*0.26m
For more information about NNBL8226-HV, please contact us.
Schwarzbeck Official Authorized Dealer:
EUTTEST is an official authorized distributor of SCHWARZBECK, whose full official name is: SCHWARZBECK MESS - ELEKTRONIK OHG
Ltd. is authorized by schwarzbeck to sell all products in China and provide technical service for the products sold.
