F-080915-1008-2 FCC 4GHz Current Injection Probe Calibration Fixture

Product Description:

F-080915-1008-2 VHF Current Probe Calibration Fixture product custom developed by Fischer Custom Communications, USA, can only be used as a single unit with FCC F-080915-1008-1 VHF Current Injection Probe, which is mainly used for military electronics VHF testing, including military radar front-end, UHF EMC testing of aerospace high-precision equipment.
VHF signal wavelength is extremely short, the fixture processing accuracy and shielding performance requirements are extremely stringent, the calibration fixture adopts high-precision conductor as the coaxial structure, which can effectively reduce the contact resistance and signal loss. The cavity adopts a double-layer shielding design, with a metal shielding layer on the outside and an insulating protective layer on the inside, which can effectively isolate the strong electromagnetic radiation in the frequency band above 3GHz and ensure the independence and accuracy of the calibration process.
Core features: Through the double-layer shielding structure and micro-cavity design, it realizes a low interference calibration environment in the VHF band, and guarantees the authenticity and traceability of the calibration data in the 3.2GHz-3.9GHz frequency band.
This product is distributed by Shenzhen EUTTEST Test Technology Co., Ltd. in China, this product is very suitable for customers who have purchased the current injection probe F-080915-1008-1 and need to calibrate it, such as EMC labs or metrology research institutes, welcome to contact us to get the product quotation information.

Technical parameters：

Insertion Loss Curve for F-080915-1008-2

Note: This product is branded as FCC - Fischer Custom Communications, Inc. and is not Federal Communications Commission (FCC) certified.

Note: Please refer to the original FCC factory data sheet for any changes in product parameters.
