HA 9250-12 Standard Gain Horn Antenna for Schwarzbeck 2GHz

Introduction：

HA 9250-12 is a standard gain horn antenna from Schwarzbeck, Germany, which is distributed by us. It is a horn antenna with linear polarization direction, for which Schwarzbeck configured a 7/16 high power connector, which ensures that EMC testers can inject 1.8kW of RF power in the 1-2GHz frequency range.

Technical parameters：

Product Specification Sheet:

HA9250-12 Gain Curve Diagram:

Antenna Gain Graph

Other optional antenna products of the same sequence:

This antenna is one of Schwarzbeck's HA 9250 serial horn antennas. If this antenna does not meet your requirements, we offer the following antennas as options:

• HA 9250-24 Test frequency 2 GHz - 4 GHz.
• HA 9250-48 Test frequency 4 GHz - 8 GHz.
• HA 9250-818 Test frequency 8 GHz - 18 GHz.

Schwarzbeck Official Authorized Dealer:

EUTTEST is an official authorized distributor of SCHWARZBECK, whose full official name is: SCHWARZBECK MESS - ELEKTRONIK OHG

Ltd. is authorized by schwarzbeck to sell all products in China and provide technical service for the products sold.

Click to view the image of the authorization
