VULP 9118 B SCHWARZBECK Log Periodic Antenna

Introduction：

VULP 9118 B is a logarithmic periodic antenna produced by schwarzbeck, Germany, authorized by Shenzhen EUTTEST agent for sale. the antenna can be used in the frequency range of 160MHz - 1500MHz for field strength (emission) measurements and radiated spurious testing of wireless products during EMC testing, you can also input 1kW RF power to conduct radiated electromagnetic field generation. You can also input 1kW RF power for radiated EMF generation. The antenna has a field attenuation measurement uncertainty of <±0.1 dB and an antenna data tolerance (gain and antenna coefficient k) of <±0.7 dB (180 MHz - 1 GHz), and can be operated in 50Ω RF test systems.

Plot of input power vs. electric field strength

For data on other distances contact EUTTEST for advice.

Technical parameters：

Product Specification Sheet:

Schwarzbeck Official Authorized Dealer:

EUTTEST is an official authorized distributor of SCHWARZBECK, whose full official name is: SCHWARZBECK MESS - ELEKTRONIK OHG

Ltd. is authorized by schwarzbeck to sell all products in China and provide technical service for the products sold.

Click to view the image of the authorization
