ATT-6dB 6dB attenuator for conducted immunity IEC61000-4-6

Order Number: EUTS0037

Test frequency: 9kHz - 1GHz

Type: Fixed attenuator

Brand: AOEMC

Min. order: 1 Unit

Stock: 0

Delivery: 15 weeks

Standards:

IEC 61000-4-6

Industry： General Electronics

Warranty: Original Import ; New Products ; Authorized Sales

Training: On-site training; Telephone; Email

Logistics: Shenzhen to National

Payment: Internet Banking T/T

Product Price:

Product Description:

The ATT-6dB is a 6dB attenuator manufactured by AOEMC for use in conducted immunity testing as required by IEC 61000-4-6 and GBT 17626.6 standards. The standard requires the use of a 6dB attenuator connected to the test and level calibration process for CDN, EM clamp, current clamp and other injection methods. The attenuator quantifies the energy absorbed in the transmission line, extends the power range, controls the power level, and can be used with power meters, integrated testers, and spectrum analyzers to accurately measure the power or spectrum of various RF microwave transmitters. It can be mounted to the grounded reference plane for cooling heat dissipation and grounding, and can also be mounted in a metal chassis, featuring small size, high precision, stability and reliability.

Technical parameters：

“Reminder: swipe tables left and right”

Model number

ATT-6dB

manufacturer

AOEMC

Available frequency

9kHz-1GHz

attenuation

6dB

accurate

±0.7dB

standing wave ratio (physics)

1.25

Input/Output Impedance

50Ω

average power

300W@25℃
Measures should be taken to ensure that the working temperature is below 100°C

connector

N male - N female

size

171×50×26mm

weight

0.35kg

Test kits

EUTTEST represents and sells the following products:

FCC-801-50-150-BCI 150Ω/50Ω Calibration Adapters
fcc-bcicf-6-150 , calibration fixture,
F-120-9A , current injection clamp.

“Reminder: swipe tables left and right”

AOEMC also offers fixed attenuator and adjustable attenuator customization. Precise attenuator construction and stable attenuation are priorities for attenuator customization, contact us for more information.
