BBV 9718 C Schwarzbeck 18 GHz Microwave Broadband Preamplifier

Introduction：

The BBV 9718 C is a microwave broadband amplifier manufactured by Schwarzbeck (Germany) and distributed under license by EUTTEST (Shenzhen). It is a low-noise, low-power broadband amplifier that can be used to increase the sensitivity of field strength measurements as well as general-purpose attenuation measurements up to 18 GHz. Thanks to a built-in rechargeable battery, it can run for about 8 hours without power. The amplifier can be used for radiometric RE testing in the darkroom up to 18 GHz. The amplifier will be placed directly behind the antenna, a suitable antenna model is available, and we can configure you with a complete antenna mounting bracket as shown below.

Picture of the back end of the mounted antenna

Technical parameters：

Product Specification Sheet:

Graph of related technical parameters：

Gain Curve Diagram

Recommendations for products in the same sequence:

EUTTEST also offers more preamplifiers manufactured by Schwarzbeck, allowing you to select the amplifier model you need based on test frequency and gain.

• BBV 9718 D 1GHz-18GHz with 30dB gain
• BBV 9719 12GHz-28GHz; gain 30dB
• BBV 9721 12GHz-40GHz; gain 30dB
• BBV 9743 B 10MHz-6GHz, 28dB gain
• BBV 9744 9kHz-6GHz with 28dB gain
• BBV 9745 9kHz-2GHz, 30dB gain
• BBV 9748 , 10MHz-8GHz , 29dB gain

Order No. EUTS0421
