FS-SET 7100 B Schwarzbeck Near Field Probe Set

Order Number: EUTS0417

Type: Near field probe

Brand: Schwarzbeck

Origin: Germany | Import

Min. order: 1 Unit

Stock:

schwarzbeck Real Time Inventory

Delivery: Click on the link above to inquire

Standards: Common Test Standards

Industry： General Electronics

Warranty: Original Import ; New Products ; Authorized Sales

Training: On-site training; Telephone; Email

Logistics: Shenzhen to National

Payment: Internet Banking T/T

Introduction：

The FS-SET 7100 B is a near-field probe kit manufactured by Schwarzbeck, Germany and authorized for sale by EUTTEST Shenzhen. The kit contains two magnetic field near-field probes and one electric field near-field probe, among other accessories:

HFSL 7101 Near Field Probe (magnetic), Frequency: 9 kHz - 30 MHz
HFSH 7102 Near Field Probe (magnetic), Frequency: 4 MHz - 1000 MHz
EFS 7103 Near-field probe (electric), frequency 9 kHz - 1000 MHz
DC Separator EW 7110
AC/DC Adapter ACDC 7110
packing box

Set of technical parameters:

“Reminder: swipe tables left and right”

Box Size

44*21*10 mm

quality

2.4kg

packing list

See list of annexes below

“Reminder: swipe tables left and right”

List of accessories included in the FS-SET 7100 B near-field probe kit:

The FS-SET 7100B Near Field Probe Kit contains a variety of the following probes and accessories, which are not sold separately.

HFSL 7101 B Magnetic Field Near Field Probe

Technical parameters：

“Reminder: swipe tables left and right”

Near Field Probe Models

HFSL 7101 B

Test Type

near-field magnetic field strength

manufacturer

Schwarzbeck

China Agent Sales

EUTTEST

Frequency range

9kHz-30MHz

connector

50Ω BNC

size

25*100mm

Maximum field strength test range

117 dBµA/m
0.7 A/m

“Reminder: swipe tables left and right”

HFSL 7102 B Magnetic Field Near Field Probe

Technical parameters：

“Reminder: swipe tables left and right”

Near Field Probe Models

HFSL 7102 B

Test Type

near-field magnetic field strength

manufacturer

Schwarzbeck

China Agent Sales

EUTTEST

Frequency range

4MHz-1GHz

connector

50Ω BNC

size

25*100mm

Maximum magnetic field test range

120 dBµA/m

Minimum Magnetic Field Test Range

5 dBµA/m

“Reminder: swipe tables left and right”

EFS 7103 B Electric Near Field Probe

Technical parameters：

“Reminder: swipe tables left and right”

Near Field Probe Models

EFS 7103 B

Test Type

near-field electric field strength

manufacturer

Schwarzbeck

China Agent Sales

EUTTEST

Frequency range

9kHz-1000MHz

connector

50Ω BNC

size

25*100mm

Maximum electric field strength test range

140 dBµV/m

Minimum electric field test range

40 dBµV/m

“Reminder: swipe tables left and right”

EW 7110 DC separator

The DC separator EW 7110 is used to supply the probes HFSL 7101 B, HFSH 7102 B and EFS 7103 B. The DC separator EW 7110 is used to supply the probes HFSL 7101 B, HFSH 7102 B and EFS 7103 B.

The DC separator and the specified probes can be used in the FS-SET 7100 B in real cases.

The power adapter ACDC 7110, which comes standard with the 7100 kit, is required for its operation.

Order No. EUTS0417
