R&S RTM Desktop Oscilloscopes

Product Description:

The R&S RTM is a general purpose oscilloscope manufactured by R&S in Germany and sold by EUTTEST in Shenzhen, China. The RTM Sequence Oscilloscopes provide precise signal display, even for long sequences, and extremely high time resolution for fast signal analysis and easy operation of the tool. The extremely low noise front-end and the A/D converter allow the user to make precise measurements even at the smallest vertical resolution. rtm oscilloscopes offer a maximum input sensitivity of 1 mV/div without any bandwidth limitation and software scaling, thus providing extremely high vertical resolution.

Product Features:

R&S RTM oscilloscopes are also available with passive and active probes. In addition to excellent measurement performance, the active probes have two innovations: the miniature pushbuttons on the probes, which can be preset to a variety of functions for direct control of the oscilloscope, and the probe voltmeter (R&S ProbeMeter), which is integrated in the probe and can be used to accurately measure DC voltages. Regardless of the channel settings of the oscilloscope's base unit, the voltmeter can quickly detect the supply voltage or the voltage at the point of operation.

R&S RTM Accurate Measurement of DC Voltage

EUTTEST can now offer its customers the oscilloscopes R&S RTM with a measurement bandwidth of 500 MHz, 2- and 4-channels, as well as passive and active probes for use with them.

R&S RTM Technical Data:

• Number of channels 2
• Bandwidth 500 (MHz)
• Sampling rate 5 (GS/s)
• Sampling depth 10 Msample euttest
• Overall dimensions 380 mm * 175 mm * 110 mm (mm)
• Weight 4.9 (kg)
• Comes standard with accessories:
• Two (2) 500 MHz passive voltage probes (10:1).
• Instructions for use
• Mainframe power cord

R&S RTM Optional Configurations and Models:

R&S®RTM1000 Digital Oscilloscope

R&S®RTM1052/1054.

Bandwidth: 500 MHz

Sampling rate: max. 2.5-5 Gsample/s

Storage depth: 4/8 Msample

ADC resolution: 8 bits

R&S®RTM2000 Digital Oscilloscopes

r&s®rtm2022/2032/2052/2102

r&s®rtm2024/2034/2054/2104

Bandwidth: 200 MHz to 1 GHz

Sampling rate: max. 2.5-5 Gsample/s euttest

Storage depth: 10/20 Msample

ADC resolution: 8 bits

R&S®RTM3000 Digital Oscilloscope

r&s®rtm3002; r&s®rtm3004

Bandwidth: 100 MHz to 1 GHz

Sample rate: Maximum 5 Gsample/s

Storage depth: Maximum 80 Msample

ADC resolution: 10 bits

Display: 10.1″ Capacitive Touch Screen

Order No. EUTS0657
