VULB 9168 Schwarzbeck Hybrid Biconical Log Periodic Antenna

Introduction：

VULB 9168 is a hybrid biconical log-periodic antenna manufactured by Schwarzbeck, Germany and authorized to be sold by Shenzhen EUTTEST agent, this is a linearly polarized log-periodic broadband antenna combined with a 4:1 broadband dipole broadband antenna, this antenna is designed to test the radiated emissions within the frequency range of 25MHz-2GHz, in addition, this antenna can only be fed with a 10W power input, so we generally recommend that laboratory customers use this antenna to test the radiated emissions without immunity testing. In addition, this antenna can only input 10W of power, so we generally recommend that laboratory customers use this antenna to test radiated emissions without immunity testing.

If you need to test for compliance with immunity, please purchase either of the following two antennas:

VULB 9162 , 25MHz-8GHz , 100W

VULB 9163 , 25MHz-4GHz , 100W

VULB 9164 , 25MHz-4GHz , 1kW

Technical parameters：

Product Specification Sheet:

Graph of related technical parameters：

Antenna Coefficient Graph

Order No. EUTS0376

Schwarzbeck Official Authorized Dealer:

EUTTEST is an official authorized distributor of SCHWARZBECK, whose full official name is: SCHWARZBECK MESS - ELEKTRONIK OHG

Ltd. is authorized by schwarzbeck to sell all products in China and provide technical service for the products sold.

Click to view the image of the authorization
