Compliance Test Studio 23 (CTS 23) EMTEST Harmonic Flicker Test Software

Order Number: EUTS0867

Type: Harmonic and Flicker Test Analysis System

Brand: EMTEST

Min. order: 1 Unit

Stock: 0

Delivery: 16 weeks

Standards: Common Test Standards

Industry： General Electronics

Warranty: Original Import ; New Products ; Authorized Sales

Training: On-site training; Telephone; Email

Logistics: Shenzhen to National

Payment: Internet Banking T/T

Product Price:

Software Overview:

EMTEST Compliance Test Studio 23 (CTS 23) is harmonic and flicker test analysis software developed by EMTEST, a subsidiary of AMETEK. It provides fundamental functionality for controlling single-phase and three-phase harmonic flicker analyzers within the EMTEST product line. EMC test personnel can analyze and test whether the company's electronic products comply with the latest harmonic or flicker test standards. Alternatively, they may select requirements from older versions of standards to meet national testing requirements.

Software Features:

All functions for uploading recorded measurement data and performing classification and analysis
Simple fault/pass function enables rapid analysis
Detailed data can be used for extended analysis and EUT evaluation.
Features robust document capabilities, enabling direct export to Word, PDF, and other file formats.

Software Testing Functions:

“Reminder: swipe tables left and right”

Software Features:

Conformity Standard No.

Harmonic Testing Function:

IEC 61000-3-2 Revisions 3.2, 4, 5, 5.1 and 5.2
IEC 61000-3-12 Revisions 1, 2 and 2.1
JIS C 61000-3-2 2005 and 2019 editions
EN 12015 2014
IEC 61000-3-16 1st Edition
ECE R10 5th and 6th editions
Ecodesign LED (CELEX 2019/2020)
Various manufacturer standards

Flicker Test Function:

IEC 61000-3-3 Revisions 1.2, 2, 3 and 3.2
IEC 61000-3-11 1st and 2nd editions
DIN EN 61000-3-3 euttest
ECE R10 5th and 6th editions
Various manufacturer standards

Features:

Standards library with pre-programmed settings, gapless logging for post-processing analysis and changing standards/classifications, PASS/FAIL evaluation, test report generator (customizable), advanced analysis with access to detailed test data

“Reminder: swipe tables left and right”

Compatible EMC Test Equipment List:

EMTEST Compliance Test Studio 23 (CTS 23) forms a harmonic and flicker test system when integrated with the following instruments. Whether your products operate on single-phase or three-phase power, this EUTTEST system meets the requirements for power supply, current, power, and test items for the vast majority of consumer and automotive electronic products.
