Schwarzbeck CDN and CDNE Coupling Decoupling Networks Product Catalog Listing

Introduction to Schwarzbeck CDN and CDNE coupled decoupling networks:

CDN Introduction:

The Chinese name of CDN is Coupling / Decoupling Networks and the English name is Coupling / Decoupling Networks, which are used to inject common mode interference into the equipment under test (EUT). In addition, CDNs provide sufficient decoupling between the auxiliary equipment (AE) and the interfering signals, and the requirements for CDNs and their applications are described in the IEC 61000-4-6 standard (Immunity to conducted interference due to radiofrequency electromagnetic fields). The CDN test method can be used on a wide range of cable types and connectors.

CDNE Introduction:

The Chinese name of CDNE is Coupling / Decoupling Networks for emission, from the English name Coupling / Decoupling Networks for emission than the CDN more than an emission: emission, so CDNE is independent of the CDN another test instrument.

CDNE is mainly derived from another type of CDN proposed by the CISPR15-2018 standard.The CDNE test method is used only for luminaire emission measurements and complies with EN 55015 of 2009.

Difference between CDN and CDNE:

CDN can use an external amplifier and signal source to inject common-mode interference into the EUT from the CDN input port; whereas CDNE can only test the RF interference component on the EUT power or signal lines, so CDNE cannot be used for power injection.

Learn more:Difference between CDN and CDNE

Schwarzbeck CDNE Coupling Decoupling Networks List of product models:

Only the following CDNE-related products are currently available for purchase.

CDNE M2
CA CDNE M2 Part A
CA CDNE Part B
SR100-6W
CDNE M3
CA CDNE M3 Part A

Schwarzbeck CDN Coupling Decoupling Network List of product models:

The following table shows the types of cables tested for the different sequences of Schwarzbeck CDN products.

“Reminder: swipe tables left and right”

CDN typology

Test Cable Type

M-shaped

electric power source
unshielded line
unbalanced line
AC or DC
Power Applications
high current

AF type

unshielded line
unbalanced line
low current

S-shaped

coaxial cable
shielded wire
shielded wire

T-shape

unshielded line
Balanced lines
telecom port
unshielded twisted pair

“Reminder: swipe tables left and right”

CDN M Sequence

M Power Cord CDN Equipment List, Mains / Power supply applications

CDN AF Sequence

Type AF Unscreened Unbalanced Lines CDN Equipment List, Unscreened unbalanced lines

CDN AF2
CDN AF3
CDN AF4
CDN AF5
CDN AF6
CDN AF8
CDN CAN-4
CDN AF SUBD
CDN AF19 SUBD
CDN10 AF3
CDN10 AF6
CDN10 AF12 SUBD
CDN10 AF17 SUBD
CDN10 AF25 SUBD

CDN S-sequence

S-Shield CDN equipment list, Screened cables

CDN T Sequence

T-type unshielded balanced lines CDN equipment list, Unscreened balanced lines

CDN for coaxial antenna input

CNA 280

Get a quote?

EUTTEST is an authorized distributor of CDNs and CDNEs from Schwarzbeck, and we can provide you with a quote for your CDNs and CDNEs from Schwarzbeck in CNY including tax, just select the model you need from the list of equipment above and contact us.
